SLS Ceramic Tile® is a preferred liner option in areas of extreme small particulate abrasion with minimal impact. The 90% fine grain, high grade alumina is manufactured to the highest standards, producing a premium product that can hold up to your most abrasive materials. Ceramic tiles offer great mechanical properties with superior sliding abrasion resistance.
Our Ceramic Tiles are offered in several thicknesses to address the requirements of your specific application. SLS Ceramic Tiles are offered with a choice of attachment methods for optimal performance.
Advantages
- Highest level of sliding abrasion resistance
- Cost effective
- Various thickness options
- Multiple attachment options
- Chemical resistance
Physical Properties COMPARISON
| Bulk Density | Young’s Modulus (MoE)* | Vickers Hardness* | Shear Modulus* | Surface Finish |
| 215 lbs/ft3 | 39 x 106 psi | 1.31 x 106 psi | 16 x 106psi | 63 μin |
* At 68° F
Standard thicknesses
| Thickness |
| 1/8″ |
| 1/4″ |
| 1/2″ |
| 3/4″ |
| 1″ |
| 2″ |
Attachment options: Epoxy or Weld-In
Note: SLS Ceramic Tile is available as a material option for repairs, rebuilds, and new fabrications only. Not for sale directly.
Related Industries
- Aggregates
- Asphalt
- Cement
- Concrete
- Foundry
- Glass
- Material Handling
- Mining
- Power Generation
- Pulp and Paper
- Recycling
- Steel Mills
